High lift pallet truck EXV 14-20
Power meets innovation
- Load capacity 2000 kg
- Rated lift 6066 mm
- Speed 6 km/h
Stronger and more intelligent than the rest – that’s the STILL EXV 14-20 high lift pallet truck. Two of its outstanding features are its huge residual load capacity and its smart colour display. The latter provides the operator with basic information, the truck status or the battery charge status at a glance, and different language-independent symbols provide optimum support in operation. The smart and extremely mobile warehouse organiser moves pallets weighing up to 2,000 kg quickly, safely and reliably. Its powerful, low- maintenance motor and precise controls, suitable for both left- and right-handed operators, enable it to achieve unprecedented pallet turnover rates.
The letters EXV are not, however, just synonymous with quick goods handling, but with safe goods handling as well. The optional load capacity diagram and Dynamic Load Control shows what is possible. The curved tiller shape and the sensitive impact plate protect the driver, and the EXV stops automatically when the tiller is released – even on ramps. The OptiSpeed tiller also adjusts the speed of the EXV to the distance from the operator, while the Curve Speed Control system regulates the speed around bends. This high lift pallet truck, which is as strong as it is smart, allows you to always keep your flow of goods safely under control; from transporting loads within the pre-storage area to operating the shelving system.
Optimum utilisation of storage area:
high storage compaction due to very high residual load capacity
Everything in view, all the time:
colour display with a range of language-independent symbols shows you all of the important functions at a glance
Always available:
battery capacities of up to 375 Ah and Li-Ion enable long periods of operation
Request to: EXV 14-20
Please fill out the form below. We will get back to you as soon as possible.
The "Simply Efficent" factors: Performance attributes as a measure of economic efficiency
Simply easy
Flexible, intuitive operation of all control elements on the tiller head
with one hand, without the need to change grip, naturally for both left- and right-handed operators
Reliable availability
thanks to large colour display with battery status display
Optimal ergonomics and reduced physical strain for the operator
thanks to electric driving, lifting and lowering functions
Clear view through the mast to the fork tips
facilitates hassle-free pallet handling
Unbeatable handling performance:
powerful motor, high residual load capacity and responsive control elements
With iGo vehicles,
additional vehicles can be added at any time so as to expand transportation capacity
Simply powerful
Power meets safety:
the four-wheel chassis ensures outstanding stability and effective performance
Reliable excellent performance
thanks to the powerful yet low- maintenance AC motor
New level of precision and safety for user and load
thanks to the responsive proportional valve control
Optimal availability, low-maintenance and high performance
thanks to the optional lithium-ion technology
Smooth and precise electrical steering
Software‑based transport controls for the EXV iGo
enable optimal fleet utilisation, whilst guaranteeing a high level of process reliability, traffic management, visualisation of truck movements, battery charge status monitoring and reduced error rates – the flow of materials and information is always reliable and mapped comprehensively and transparently
Simply safe
Maximum driver safety
thanks to the low-entry truck frame and load backrests
Initial lift ensures stable and low-vibration driving performance,
even if there are slight gradients or unevenness in the floor
Safety for man and machine:
OptiSpeed tiller and automatic stop mechanism when the tiller is released
Safe manoeuvring even in restricted space
thanks to creep speed mode
Information on the lift height at a glance
– on the coloured load capacity display
Estimate the load correctly:
Dynamic Load Control can be used to estimate the load and the corresponding maximum lift height
EXV iGo
improves transport quality and eliminates the risk of injury and damage to people, trucks, warehouse equipment and goods thanks to smart safety functions
Simply flexible
Precision even in confined spaces
thanks to compact dimensions
Well-equipped for a wide range of applications
with different driving programmes
Ready for use at all times:
the battery can be charged and interim charged flexibly from any location without the need for a fixed charging station
iGo trucks can also be operated manually if required:
this increases flexibility, safeguards process and material flow and enables easy access to goods
Simply connected
Compact information:
all relevant truck information is available at a glance in the STILL neXXt fleet web application.
Innovative STILL FleetManager keeps driver and truck safe:
operator management and shock detection as well as damage and cost minimisation thanks to access protection
Optimisation of the goods flow
thanks to straightforward connection to existing material flow management systems via MMS provision
Different iGo trucks can be combined
with one another, and with manual transport systems and stationary automation systems
STILL Li-Ion Technology inside
The perfectly harmonised power system for reducing operating costs and increased truck availability.
More about STILL Li-Ion Technology
Request to: EXV 14-20
Please fill out the form below. We will get back to you as soon as possible.
Maximum safety:
Smart safety functions increase transport quality and eliminate the risk of accidents and damage to people, vehicles, warehouse equipment and goods.
Outstanding process excellence:
Avoidance of incorrect withdrawals and empty runs increases transport quality
Maximum availability:
Efficient transport control and IT integration enable optimum fleet utilisation around the clock
Optimum cost-effectiveness:
Efficiency through individual automation concepts as well as transparent and optimised continuous material flow
| Model | Maximum capacity (kg) | Maximum lift height (mm) | Travel speed (km/h) | Battery voltage (V) |
|---|---|---|---|---|
| EXV 14 (i) / Li-Ion | 1.400 | 6.066 | 6.0 | 24 |
| EXV 14 D / Li-Ion | 1.400 | 6.066 | 6.0 | 24 |
| EXV 16 (i) / Li-Ion | 1.600 | 6.066 | 6.0 | 24 |
| EXV 16 D / Li-Ion | 1.600 | 6.066 | 6.0 | 24 |
| EXV 20 (i) / Li-Ion | 2.000 | 4.476 | 6.0 | 24 |
| EXV 20 D / Li-Ion | 2.000 | 4.476 | 6.0 | 24 |
| EXV iGo /Li-Ion | 2.000 | 3.000 | 6.0 | 24 |
Downloads
The document provided for download is the updated version of the operating instructions for the standard truck. It does not include descriptions of customer options (Customer Option). For a concrete truck, please request the respective specific manual according to the serial number and the year of production from the STILL spare parts service.
